We have welcomed another big pen plotter to the fleet. The notorious HP 7596A DraftMaster II. In this post I’ll cover the whole process from buying an in unknown working state vintage plotter, hauling it back home, to getting it ready for some serious production work.
The iconic cover of Joy Division’s legendary debut album “Unknown Pleasures” (1979) features a striking image of a pulsar’s radio waves. I always liked Joy Division (and New Order) and thought it would be a fun project to recreate the Ridgeline plot on a period(-ish) correct pen plotter. In this post the approach will be outlined without getting too much into details.
We use a lot of paper in our plotting endeavours. Here’s an insight in one of the cool plotter products of the era.
We got some new gear. Really nice old sturdy gear from 1988. We were having a blast with it while testing and fixing problems.
